TP-Link TL-SG1005LP 5 Ports Ethernet Switch

  • Part: 1284516
  • Model: TL-SG1005LP
$69.00

Availability

In Stock

Professional 5-Port Gigabit Switch with 4 PoE+ Ports

Plug and Play, with PoE power supply which meets the needs of diverse devices.

TL-SG1005LP

40 W PoE Budget
Plug and Play
Multicast Optimization
QoS for Traffic
Prioritization
Intelligent Power
Management
Durable Metal Casing

Dedicated 4-Port PoE+ Switch (40 W Budget) for Numerous Applications

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 40 W PoE power budget for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

Plug and Play, No Configuration Required

Plug In
Connect Devices
Enjoy

Intelligent Power Management

When total power consumption exceeds 40 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port's power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

Advanced Functions for Higher Performance

Qos
For Fluent Online Experience

Administrators can designate the priority of traffic based on QoS, for example, to ensure that voice and video applications remain clear and lag-free.

IGMP
Snooping
Traffic Optimization for IPTV

IGMP Snooping optimizes multimedia traffic delivery, to ensure a better network experience especially for applications like IPTV.

Durable Metal Casing

The interior components of TL-SG1005LP are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SG1005LP delivers switching performance you can depend on.

Compact Desktop Design
Wall-Mounting
Fanless Design

  • General Information
    • Manufacturer
    • TP-LINK Technologies Co., Ltd
    • Manufacturer Website Address
    • http://www.tp-link.com.au
    • Brand Name
    • TP-Link
    • Product Type
    • Ethernet Switch

  • Interfaces/Ports
    • Total Number of Network Ports
    • 5
    • Port/Expansion Slot Details
    • 4 x Gigabit Ethernet PoE+
    • 1 x Gigabit Ethernet Network
  • Media & Performance
    • Media Type Supported
    • Twisted Pair
    • Ethernet Technology
    • Gigabit Ethernet
    • Network Technology
    • 1000Base-T
  • Network & Communication
    • Layer Supported
    • 2
  • Management & Protocols
    • Manageable
    • No
  • Power Description
    • PoE (RJ-45) Port
    • Yes
    • PoE Budget
    • 40 W
    • Power Source
    • PoE+
    • Power Adapter
    • Power Consumption
    • 47.50 W
  • Physical Characteristics
    • Form Factor
    • Compact
    • Desktop
    • Wall Mountable
    • Height
    • 25 mm
    • Width
    • 99.8 mm
    • Depth
    • 98 mm
    • Weight (Approximate)
    • 230 g
  • Miscellaneous
    • Environmentally Friendly
    • Yes
